When upgrading the stock halogen / incandescent lamps to led lighting bulbs, the bulb size guide will be much helpful, below are the bulb size guide for 2005~2017 Chevrolet Equinox; yet it is for reference only, it is suggested to check the owner manual to confirm the bulb size guide is correct before purchasing.
- High beam headlight and Low beam headlight for 2005~2009 Chevy Equinox: 9007 for 2010~2017 Chevy Equinox High beam headlamp: 9005 / 9005LL; Low beam headlight: H11
- Fog light: H11 / H8 / H8LL / H11LL
- Front turn signal light ( blinker light) for 2005~2009 Chevy Equinox: 1156A / 1156NA; for 2010~2017 Chevy Equinox: 7444NA / 7443-SCK
- Rear turn signal light / Brake Tail light for 2005~2009 Chevy Equinox: 2057 for 2010~2015 Chevy Equinox: 3157/ 3157KX for 2016~2017 Chevy Equinox: 7443 / 7443LL
- Back-up reverse light: 921 / 921K
- 3rd Brake light / Center high mount stop light: LED
- License plate light / Tag light: 194 / W5W / 2825
- Interior Dome light for 2005~2009 Chevy Equinox: 561 ; for 2010~2017 Chevy Equinox: 2825
- Interior Map light: 2825 / 906 / 2825L
- Luggage compartment light for 2005~2009 Chevy Equinox: 562; for 2010~2017 Chevy Equinox: 194
- Vanity mirror light: 6612F
- Stepwell light: 175
- Front and rear side marker light: 168 / 194 / 2825
